This Massey Ferguson tractor high-powered engine of 85 horsepower.
Even though it contains a robust diesel engine which has an additional feature of reduced noise.
With keeping in mind, the regulation of ECE R49, gaseous and smoke emission are notably decreased.
There is an oil cooler installed to maintain the high-powered engine cool even in high-temperature regions.
The latest technology, hydrostatic power steering, is also one of many features for better wheel operation and easy steering wheel movement.
An oil-immersed multi-brake system is installed for a smooth experience.
There are comfortable home-like deluxe seats and sturdy spring suspension installed.
Along with this striking Massey tractor, we provide you with quick services at your doorstep.
We guarantee the availability of all parts.
| Engine Power at 2,200 rpm> | 85 (B.S) hp |
| Torque at 1,400 rpm | 212 Nm |
| PTO Power at Rated Engine Speed | 70 hp |
| *Certified at BS AU 141a | **Manufacturer's estimate |
| Voltage | 12V, Negative Earth |
| Battery | 110 Ah |
| Starter | 2.8 kW |
| Alternator | 45 Amp |
| Type | Sliding Spur |
| Number of Gears | 8 Forward, 2 Reverse |
| Road Speed at 2,200 | Engine RPM with 18.4/15-30 rear tyres |
| Gear | Speed (km/hr) |
| Forward 1 (First Low) | 2.7 |
| Forward 2 | 3.7 |
| Forward 3 | 5.1 |
| Forward 4 | 6.8 |
| Forward 5 (First High) | 10.4 |
| Forward 6 | 15.2 |
| Forward 7 | 20.8 |
| Forward 8 | 27.9 |
| Reverse 1 (Low) | 3.5 |
| Reverse 2 (High) | 14.1 |
| Functions | Draft Control, Position Control Response Control, Constant Pumping |
| Pump Type | 4 Piston, Ferguson Pump |
| Oil Flow | 16.7 ltr/min |
| Pressure | 21.2 Mpa at normal operating temperature |
| Lift Capacity with Lower | 2,145 kg |
| Links Horizontal | |
| Lower Links | With Cat. I & II Interchangeable Balls |
| Axle Type | Straddle with apicyclic redution unit |
| Brake Type | Oil immersed, Multi-disc |
| Brake Pedal | Pendant |
| Braking Area | 1.774 sq. cm |
| Brake Actuation | Hydraulic |
| Parking Brake | Hand Lever Operated |
| Front | 7.50 - 16 (6PR) |
| Rear | 18.4 / 15 - 30 (6PR) |
| Type | Dual |
| Diameter | 305 x 254 mm |
| Lining Material | Cerametallic |
| Type | Heavy Duty Box Section, Adjustable |
| Type | Hydrostatic |
| Front Axle | 1,271 - 1,881 mm |
| Rear Axle | 1,423 - 2,134 mm |
| Make / Type | Diesel / 4.41 |
| No. of Cylinders | 4 |
| Injection | Direct |
| Bore | 101 mm |
| Stroke | 127 mm |
| Capacity (litres) | 4.1L |
| Compression Ratio | 15.3:1 |
| Aspiration | Natural |
| Starting Aid | Thermostart |
| Throttle Control | Hand and Feet |
| Cooling | Water |
| Air Cleaner Type | Oil Bath |
| Air Pre-Cleaner | Over Bonnet |
| Fuel Filter | Dual, High Capacity |
| Exhaust | Vertical Muffler |
| Oil Cooler | Water Cooled |
| Type | Live |
| Engine Speed at 540 pto rpm | 1,789 rpm |
| Shaft Diameter | 35mm |
| No. of Splines | 6 |
| Guages | Technometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature |
| Warning Lights | Direction Indicators, Electric Charge, Headlight Main Beam, Low Engine Oil Pressure, Brake Lights & Auxiliary Socket |
| Gross Weight | 2,435 kg |
| Wheel Base | 2,286 mm |
| Overall Length | 3,760 mm |
| Overall Width (Min) | 1,871 mm |
| Over Exhaust | 2,485 mm |
| Over Steering Wheel | 1,781 mm |
| Without Brakes | 7,502 mm |
| Under Gear Box | 501 mm |
| Fuel Tank | 108.0L |
| Engine Pump | 7.5 L |
| Cooling System | 15.2L |
| Hydraulic System | 36.0L |
| Hydrostatic Steering Reservior | 2.0L |
| Oil Bath Air-Cleaner | 0.7 L |
| Brake Oil | 0.25L |
